How to get Azure Backup Protection Containers?

When working with the Azure REST API, I had the requirement to get the Recovery Service Vaults Backup Protection Containers. Naturally, like many, I went to the Microsoft Azure REST API documentation website to learn how to call this API, but when following it I hit a few issues that was not clear and not part of the documentation. Here below are some of the issues I had, that I hope can solve yours… If your having any.

This is the link to the documentation if you don’t have it already to follow.
https://docs.microsoft.com/en-gb/rest/api/backup/backupprotectioncontainers/list

Get All Doesn’t Work

As you can see from the documentation you should be able to call the GET request for:

GET https://management.azure.com/Subscriptions/{subscriptionId}/resourceGroups/{resourceGroupName}/providers/Microsoft.RecoveryServices/vaults/{vaultName}/backupProtectionContainers?api-version=2016-12-01

This should be a non-filtered list of all the containers not matter their type. However, when calling this you will get the error saying you are missing required properties. With such a helpful message response, how could you not understand what is going wrong.

What I have found is you need to use the filter request, but it is still not that simple. From the example in the documentation you can use the Backup Management Type. However, if like me you want all the containers no matter the type then this isn’t the most helpful, so looking into the OData filters documentation you can use many other requests.

Instead of doing backupManagementType eq ‘AzureWorkload’ which is Backup Management Type equals Azure Workload, you can use ‘ne’ that is not equal to. With this you can put some random text in the string to say Get All Backup Protection Containers Where Backup Management Type Does Not Equal RandomWords. Makes sense yes? Well not for this API. This still results in the same error. I even tried to change the parameter it is searching on to something all valid containers should have like ‘registrationStatus’, but that didn’t work.

The only method I got this API call to work was to call it with the filter of Backup Management Type.

Trying to reduce code I added the Backup Models from the Nuget Package Microsoft.Azure.Management.RecoveryServices.Backup

Azure C# SDK missing options

As stated above you need to use the filter with Backup Management Type to get the Protected Containers, so to get all of them we need to call each type. As I don’t know all the types,  I found the Enum BackupManagementTypes in the above Nuget package that I can then loop through.

However, I am not sure if it is just out of date or that the Nuget package is in preview, but no all the types are in there. Therefore, I created my own using the values in the API Documentation.

/// <summary>
/// Azure Backup Management Types
/// https://docs.microsoft.com/en-gb/rest/api/backup/backupprotectioncontainers/list#backupmanagementtype
/// </summary>
        public enum BackupManagmentTypes
        {
            AzureBackupServer,
            AzureIaasVM,
            AzureSql,
            AzureStorage,
            AzureWorkload,
            DPM,
            DefaultBackup,
            Invalid,
            MAB
        }

Then it can beĀ  used like this:

foreach (var backupManagementTypeStr in Enum.GetValues(typeof(BackupManagmentTypes)))
{
	var urlWithFilter = $"{containerUrl}&$filter=backupManagementType eq '{backupManagementTypeStr}'";
}

Azure C# SDK incorrect format

With the Nuget package I thought I could the Desterilise the response into the class ProtectionContainerListResponse as this is what the documentation says the type is, but it failed as the model of this class follows ‘response.ItemList.ProtectionContainers’, whereas the expected response follows ‘response.values’

When looking at the response in the API Documentation I have also seen a pattern to the response types for the Recovery Service API. They all have a list with ‘nextlink’ and ‘values’, which values is a list of the response type. However, the types in the list also follow the same pattern with all the properties the same except what type the property ‘properties’ is. Therefore, you can make a generic response as below:

  /// <summary>
        /// API Response
        /// </summary>
        public class ResourceResponse<T> where T : class
        {
            /// <summary>
            /// The uri to fetch the next page of resources. Call ListNext() fetches next page of resources.
            /// </summary>
            public string nextLink { get; set; }
            /// <summary>
            /// List of resources.
            /// </summary>
            public List<ResourceDetails<T>> value { get; set; }
        }

        /// <summary>
        /// Resource Details
        /// </summary>
        public class ResourceDetails<T> where T : class
        {
            /// <summary>
            /// Optional ETag.
            /// </summary>
            public string eTag { get; set; }
            /// <summary>
            /// Resource Id represents the complete path to the resource.
            /// </summary>
            public string id { get; set; }
            /// <summary>
            /// Resource location.
            /// </summary>
            public string location { get; set; }
            /// <summary>
            /// Resource name associated with the resource.
            /// </summary>
            public string name { get; set; }
            /// <summary>
            /// resource properties
            /// </summary>
            public T properties { get; set; }
            /// <summary>
            /// Resource tags.
            /// </summary>
            public object tags { get; set; }
            /// <summary>
            /// Resource type represents the complete path of the form Namespace/ResourceType/ResourceType/...
            /// </summary>
            public string type { get; set; }
        }
