Use Terraform to connect ACR with Azure Web App

You can connect an Azure Web App to Docker Hub, Private Repository and also an Azure Container Registry(ACR). Using Terraform you can take it a step further and build your whole infrastructure environment at the same time as connecting these container registries. However, how do you connect them together in Terraform?

I am going to focus on the connection of an ACR, but you can also follow the same method for the other providers.

Why I am using this as an example, is when correcting the other methods they are a simple URL, username and password, but the Azure Container Registry within the portal has a different user interface where it connects natively in the Azure. Why I was learning to do this, I kept getting my ACR connecting like a private repository instead of an actual ACR. Therefore, the method below will have the desired outcome of within the Azure portal the Web App showing it is connected to an ACR.

I will go through the general setup I have got for a simple Web App connecting to an ACR with all of the supporting  elements. I am not showing best practice of having the variables and outputs in separate files as this is not the point of the post, but I would encourage people to do that.

First we will need to create the infrastructure to support the Web App, by connecting to the Azure Resource Manager provider in Terraform:

provider "azurerm" {
  version         = "=2.25.0"
  subscription_id = var.subscription_id
  features {}
}

This passes a ‘subscription_id’ variable to connect to the correct subscription. We then create the Resource Group to contain all the resources.

variable "resource_group_name" {
  type        = string
  description = "Azure Resource Group Name. "
}
variable "location" {
  type        = string
  description = "Azure Resource Region Location"
}

# Create a Resource Group
resource "azurerm_resource_group" "acr-rg" {
  name = var.resource_group_name
  location = var.location
}

The next part is to create the Azure Container Registry with your chosen name and the SKU for the service level you would like. For this example we have use the ‘Standard’ to keep it cheap and simple, while using the same location as the Resource Group.

variable "container_registry_name" {
  type        = string
  description = "Azure Container Registry Name"
}

# Azure Container Regristry
resource "azurerm_container_registry" "acr" {
  name                     = var.container_registry_name
  resource_group_name      = azurerm_resource_group.acr-rg.name
  location                 = azurerm_resource_group.acr-rg.location
  sku                      = "Standard"
  admin_enabled            = true
}

For the Web App we will need an App Service Plan to contain the Web App and set the SKU Level. You can see this is the same as before using the same locations and also I am using Linux as the base operating system.

variable "app_plan_name" {
  type        = string
  description = "Azure App Service Plan Name"
}

# App Plan
resource "azurerm_app_service_plan" "service-plan" {
  name = var.app_plan_name
  location = azurerm_resource_group.acr-rg.location
  resource_group_name = azurerm_resource_group.acr-rg.name
  kind = "Linux"
  reserved = true
  sku {
    tier = "Standard"
    size = "S1"
  }
}

Now is where we declare the Web App itself, but first create the 3 variables we will need. The Web App name, your Registry name and the Tag assigned to your image.

variable "web_app_name" {
  type        = string
  description = "Azure Web App Name"
}
variable "registry_name" {
  type        = string
  description = "Azure Web App Name"
}
variable "tag_name" {
  type        = string
  description = "Azure Web App Name"
 default: 'latest'
}

To link to Docker Registries you need 3 App Settings configured ‘ DOCKER_REGISTRY_SERVER_URL’, ‘ DOCKER_REGISTRY_SERVER_USERNAME’, and ‘DOCKER_REGISTRY_SERVER_PASSWORD’.

These are used to gain the correct access to the registries.

For the ACR, the URL is the ‘Login Server’ and then the username/password is the Admin Username/Password.

These can be found here in the portal, if your ACR is already created.

For example:

    DOCKER_REGISTRY_SERVER_URL      = "https://myacr.azurecr.io"
    DOCKER_REGISTRY_SERVER_USERNAME = myacr
    DOCKER_REGISTRY_SERVER_PASSWORD = *********

A key part to see here is the URL is prefixed with the ‘https’ and it needs to be this, not http as it needs to be secure.

Instead of getting these details manually, we are using Terraform so we have access to these details from the created Azure Container Registry that we can use:

    DOCKER_REGISTRY_SERVER_URL              = "https://${azurerm_container_registry.acr.login_server}"
    DOCKER_REGISTRY_SERVER_USERNAME = azurerm_container_registry.acr.admin_username
    DOCKER_REGISTRY_SERVER_PASSWORD = azurerm_container_registry.acr.admin_password

We now have a connection to the ACR, but need to tell the Web App what registry and tag to look for. As we are using a Linux based server, we configure the ‘linux_fx_version’ in the site config with this pattern below, but for Windows you would use ‘windows_fx_version’.

"DOCKER|[RegistryName]:[TagName]"

For an example with a registry name MyRegistry and a tag name MyTag:

"DOCKER|MyRegistry:MyTag"

Below is the full example of the Web App generation in Terraform. With all these parts together you should have a Resource Group containing a ACR, App Service Plan and a Web App all connected.

# web App
resource "azurerm_app_service" "app-service" {
  name = var.web_app_name
  location = azurerm_resource_group.acr-rg.location
  resource_group_name = azurerm_resource_group.acr-rg.name
  app_service_plan_id = azurerm_app_service_plan.service-plan.id
  app_settings = {
    WEBSITES_ENABLE_APP_SERVICE_STORAGE = false

    # Settings for private Container Registires
    DOCKER_REGISTRY_SERVER_URL      = "https://${azurerm_container_registry.acr.login_server}"
    DOCKER_REGISTRY_SERVER_USERNAME = azurerm_container_registry.acr.admin_username
    DOCKER_REGISTRY_SERVER_PASSWORD = azurerm_container_registry.acr.admin_password

  }
  # Configure Docker Image to load on start
  site_config {
    linux_fx_version = "DOCKER|${var.registry_name}:${var.tag_name}"
    always_on        = "true"
  }
  identity {
    type = "SystemAssigned"
  }
}

## Outputs
output "app_service_name" {
  value = "${azurerm_app_service.app-service.name}"
}
output "app_service_default_hostname" {
  value = "https://${azurerm_app_service.app-service.default_site_hostname}"
}
